1. Provide quality guarantee
2. Provide customers with special customized services
3. Buy terminal to send hydraulic tools
4. Fast delivery
5. Free sample
6. Cost-effective
Material: Nickel plated brass
Clamping part: Nylon PA, UL94-V2
Sealing element: NBR
Thread Type: PG according to DIN 40430
Test Standard: EN50262/EN62444
Protection class: IP68(O-ring and the wire/cable under the
condition of clamping range )
Range of temperature: -40℃ to +100℃
Using range: Suitable for all sealing,fixed,anti-skidding,the
occasion of high temperature requirements.
suggestion: If you need oter marterial of sealing element, such as
Silicone, EPDM,etc.
Please feel free to contect us!
Package and Shipping
inside: standard quantity in one plastic bag
outside: some quantity in one papercarton
customized packing also be available
Parameters
| Thread AG | Cable range(mm) | Thread Length(GLmm) | Combined length | Spanner size(mm) | AGmm |
| M12*1.5 | 3-6.5 | 7 | 6 | 14 | 16 |
| M16*1.5 | 4-8 | 8 | 7 | 19 | 18 |
| M18*1.5 | 5-10 | 8 | 7 | 21 | 20 |
| M20*1.5 | 6-12 | 8 | 7.5 | 22 | 22 |
| M22*1.5 | 10-14 | 8 | 7.5 | 24 | 24 |
| M24*1.5 | 11-15 | 9 | 8 | 27 | 25 |
| M25*1.5 | 12-16 | 9 | 8 | 30 | 27 |
Questions & Answers
Q1 : Can I have a sample for test ?
Yes , Sample order is welcomed , the lead time will be 3-5 working
days acoording to your request .
Q2 : How about the lead time ?
Sample order need 3-5 working days , mess order need 15-20 working
days .
Q3 : Do you have certificates about the waterproof connectors ?
Yes , we have got UL for T type series , CE for all waterproof
connectors .
Q4 : What payment can you accept ?
We are appreciate that you can pay via T/T , and of course you can
pay by L/C , Western Union , Paypal .
Q5 : Is that OK to print our Logo on your product and package ?
Yes , it is OK . Before our production please inform us formally ,
and confirm the design firstly based on the sample that we send to
you .
Q6 : Are you a factory ? Where is your factory ?
Yes , we are a factory , we located in Shenzhen .
Q7 : Do you accept OEM & ODM service ?
Yes , we accept OEM service. We will produce according to your
requirment .ODM are also welcomed . Our engineers have more than 10
years experience for waterproof connector industry . we provide our
best service for your refer.
Q8 : How much does it cost to my country ?
The freight will be given by fright company based on your Gross
weight and CBM .
Q9 : Can I order 100m cable for 1pc waterproof connector ?
Yes , for waterproof connector ,we can connect with 10cm , 1m , 2m
,5m , 10m , 50m , 100m and so on , will produce according to your
detailed requirement .
Product Details
