    Waterproof Power Cable Connectors 4 Pin Male And Female Waterproof Connector

    Ask Lasest Price
    Brand Name : Realeader
    Model Number : DR-D13
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram , Paypal
    Supply Ability : 100000pieces/Month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Waterproof Power Cable Connectors 4 Pin Male And Female Waterproof Connector

    Waterproof Power Cable Connectors 4 Pin Male And Female Waterproof Connector

    Product Description

    Description:
    1. Direct plug-in docking assembly, simple to use and convenient installation;
    2. For low voltage, low current of signal products tailored;
    3. The plug with compact structure and dainty appearance, is more suitable for the demand;
    4. Innovation and development in 2008, the first generation of electric bicycle universal singal lines.
    5. Mainly used for electric bicycle accessories and other signal lines.

    Features:


    Operating Temperature : PA66 : -40℃~+105℃

    Plug/Unplug durability : 1500times

    Connection Mode : Screw Threaded


    Data Sheet


    Connecting ModeScrew Threaded
    Cable Specification1.5mm2 / 20 - 14AWG
    Cable Range0-9mm
    Rated Current10A
    Rated Voltage250V AC
    Protection LevelIP67
    Contact Resistance10mΩ
    Insulation Resistance200MΩ
    Operating TemperaturePA66 : -10℃~+105℃

    Specification


    SizeMale : Φ15.5*45mm Female : Φ18.3*45.8mm
    Male Pin DiameterΦ2.35mm
    Male Pin MaterialCopper/Copper Alloy (Gold plating/Nickel plating)
    Female Pin MaterialCopper/Copper Alloy (Gold plating/Nickel plating)
    Over-Mold MaterialPA66
    Insulator MaterialPA66
    Wire Specifications20AWG---14AWG
    Wire DiameterΦ4.0-Φ9.0
    Protective LevelIP67

    Payment Terms


    1. 100% T/T in advance .

    2. T/T , Paypal , Western Union , L/C .


    Questions & Answers


    Q1 : Can I have a sample for test ?

    Yes , Sample order is welcomed , the lead time will be 3-5 working days acoording to your request .


    Q2 : How about the lead time ?

    Sample order need 3-5 working days , mess order need 15-20 working days .


    Q3 : Do you have certificates about the waterproof connectors ?

    Yes , we have got UL for DL-A02 series , CE for all waterproof connectors .


    Q4 : What payment can you accept ?

    We are appreciate that you can pay via T/T , and of course you can pay by L/C , Western Union , Paypal .


    Q5 : Is that OK to print our Logo on your product and package ?

    Yes , it is OK . Before our production please inform us formally , and confirm the design firstly based on the sample that we send to you .


    Q6 : Are you a factory ? Where is your factory ?

    Yes , we are a factory , we located in Shenzhen .


    Product Details


    Male Size : Φ15.5*45mm

    Female Size : Φ18.3*45.8mm

    Contact Cores : 2pin / 3pin

    Male Pin Diameter : Φ2.35mm

    Male Pin Material : Copper/Copper Alloy (Gold plating/Nickel plating)

    Female Pin Material : Copper/Copper Alloy (Gold plating/Nickel plating)

    Over-Mold Material : PA66

    Insulator Material : Nylon, Temperature-resistance 260℃

    Wire Specifications : 20AWG---14AWG

    Wire Diameter : Φ4.0-Φ9.0

    Protective Level : IP68

    Working temperature : -40℃~ 125℃

    Rated Current : 10-12A

    Rated Voltage : 250V

    Test Voltage : 1000V~1500V

    Contact Resistance : 10 MΩ

    Insulation Resistance : 200 MΩ
